absolute line pin loaded dual function
PLX-9200 MULTI PRESS
MULTI PRESS

cod. PLX-9200

  • KEY POINTS
  •  SINGLE PUSH
    leverage system
     High-density foam cushions
    with PU upholstery
     ADJUSTMENTS
    main force leverage on 6-level, seat height on 5-level, backrest forward/backward on 3-level
     WEIGHT STACK 100 kg
    with full protection cage

The images and data in the catalogue and in the site tabs may differ in some details from the originals

Technical data

Saddle
SaddleHigh-density foam cushions with PU upholstery
Max user weight
Max user weight120 Kg
Use
UseCOMMERCIAL USE
Characteristic
Characteristic
  • Weight stack steel 90 kg with full protection cage
  • Pulley system made of POM, a very stiff material with low surface friction and good dimensional stability - PREMIUM GRADE bearings
  • Cables system steel woven cables ø5 mm, max. loadable weight 1500 kg
  • Adjustments: main force leverage on 6-level
  • Adjustments: seat height on 5-level
  • Adjustments: backrest forward/backward on 3-level
  • Seat adjustment with pantograph system assisted by gas spring
Frame
FrameStructure oval flat heavy-duty steel tubing oval 50x100 mm - thickness 3 mm and round ø 60 mm - thickness 3 mm.
Weight
Weight235 kg
Set up size
Set up size1365x1363x1602 mm
Gross weight
Gross weight264 kg
Painting
PaintingPainting double heavy duty powder coating painting, scratch-resistant. Tubing treatment with sandblasting and phosphating process.
Compliances
CompliancesEN20957-1 / EN957-2 classe S
Product code
Product codePLX-9200
EAN
EAN8029975807003
