ASX-7000

Professional
Vertical

| News |
IT

all in one: ASX-7000; NEW

3-IN-1 dual pulley, smith machine, rack; cod. ASX-7000

KEY POINTS
WEIGHT STACKS
2 x 90 KG

PULLEY
adjustable on 50 levels (300-1875 mm) distance 25-50 mm

MAX USER WEIGHT
160 Kg

BARBELL
1282 mm, linear bearings sliding, 2 safety systems with hook to avoid barbell falling, vertically adjustable on 11 levels (455-1750 mm), distance 130 mm. Weight plate holder diameter suitable for ø50 mm weight plates. Patented system to link the barbell to the weight stacks.

EQUIPMENT
dual pulley, smith machine, rack. Chin-up bar, 8 olympic spring clips ø49 mm. Attachments : ankle strap, rope, chain, 2 D- handles, V-bar, short straight bar, straight bar and curved bar

RATIO
1:2 / smith bar - 1:2 / fly handle - 1:2 / lat pull down - 1:2 / seated rowing

ASX 7000 is a prestigious model at the top of Toorx's All in One line, undisputed leader in this market segment. In addition to boasting technical features and performance of absolute importance, in addition to the possibility of connecting the guided barbell to the weight packs and in addition to an exclusive and complete range of attachments to make it even more multifunctional, the ASX 7000 also boasts an elegant and pleasant look and a very small ground footprint, characteristics not common in the All in One category. These important advantages allow it to find its place in the most refined and sophisticated environments, even when the space available is a critical point.

The images and data in the catalogue and in the site tabs may differ in some details from the originals

COMPARE

Technical data

Max user weight
Max user weight	160 kg
Characteristic
Characteristic	Steel weight stack 2x90 kg with protective casing PULLEY regolabile 300-1875 mm su 50 livelli interasse 25-50 mm BARBELL 1282 mm, linear bearings sliding, 2 safety systems with hook to avoid barbell falling, vertically adjustable on 11 levels (455-1750 mm), distance 130 mm. Weight plate holder diameter suitable for ø50 mm weight plates. Patented system to link the barbell to the weight stacks. EQUIPMENT 3-IN-1 dual pulley, smith machine, rack. Chin-up bar, 8 olympic spring clips ø49 mm. ATTACHMENTS: ankle strap, rope, chain, 2 D- handles, V-bar, short straight bar, straight bar and curved bar OPTIONAL COD. LEG-PRESSASX Vertical leg press COD. M-BARASX Multifunctional bar COD. MLIFTASX-4.5-6 Monolift COD. LAT-SEATASX-4.5-6 Lat seat COD. W-HOLDERASX Weight plates holder COD. LPDASX-4.5-6 Lat pull down COD. J-ARMSASX6000 Jammer arms COD. W-HOLDERASX-7 6 pcs weight plates holders COD. D-HANDLEASX-7 Dip handle COD. W-HOLDER-SMASX-7 Set of 2 weight plates holders for smith bar COD. LMASX-7 Landmine COD. SB-FSASX-7 J-cups and safety spotter arms COD. LR-FOOTPLATEASX-7 Low row foot plate
Frame
Frame	Structure section rectangular tubing 50x70 mm - thickness 2,5 and oval 50x100 – thickness 2,5 mm
Weight
Weight	382.8 kg
Set up size
Set up size	1320 x 1520 x 2180 mm
Compliances
Compliances	EN20957-1 / EN957-2 class S
Product code
Product code	ASX-7000
